Bio:

Dr. Cadmus Yuan is currently a Professor in the Department of Mechanical and Computer-Aided Engineering at Feng Chia University. Dr. Yuan graduated from National Tsing Hua University in Hsinchu, obtaining his Ph.D. in Power Mechanics in 2005, with a major in Solid Mechanics. After graduation, he conducted postdoctoral research at the Technology University of Delft in the Netherlands. He is focusing on applying AI method and Finite Element Method (FEM) to semiconductor packaging design, reliability issues, and smart manufacturing technologies.

Abstract:

  With the advent of cutting-edge technologies such as artificial intelligence (AI), autonomous driving, and heterogeneous integration, electronic packaging has evolved toward more complex and miniaturized architectures—such as chiplet-based systems and high-density interconnects. These advances bring significant challenges to mechanical reliability, particularly concerning solder joint fatigue in plastic ball grid array (PBGA) packages under thermal and mechanical loads.
  To address such reliability concerns, finite element modeling (FEM) has become a widely adopted tool for virtual prototyping. While FEM offers high-fidelity simulations, it remains computationally intensive and requires domain expertise for material calibration, boundary condition settings, and result interpretation. These constraints render FEM impractical for early-stage design iterations that demand rapid evaluation over vast design spaces.
 This invited talk introduces a hybrid framework that integrates AI-based surrogate models with conventional FEM simulation workflows. Rather than replacing FEM, our framework leverages the complementary strengths of both approaches: AI models for rapid inference and exploration, and FEM for high-accuracy validation and critical case analysis. This co-existence strategy enables scalable, cost-effective reliability design in industrial settings.
  A deep neural network (DNN) architecture is proposed as the core surrogate engine. The model is trained on deterministic FEM-generated datasets and designed to capture multi-dimensional, nonlinear design-to-response mappings. Once trained, the surrogate model enables fast approximations, optimization via gradient descent (GD) or particle swarm optimization (PSO), and large-scale Monte Carlo simulations for sensitivity analysis and uncertainty quantification. The resulting insights can be used to filter and prioritize design candidates before passing them to FEM for detailed verification.
This talk will highlight:
The motivation and architecture of the AI-FEM co-design framework.
The methods to train the AI model with new training indicators
The application of the surrogate model in reliability optimization and uncertainty assessment within the AI-FEM loop.
By embedding intelligence early in the design process, this framework bridges physics-based modeling and data-driven inference, enabling more efficient and informed design decisions for next-generation electronic packaging.



Bio:
Wataru Doi received joined Murata Manufacturing Co., Ltd. in 2009. He specializes in sealing and bonding technologies for packaging. Since 2021, he has been involved in warpage control for 300 mm COW as part of the WOW Alliance at Tokyo Institute of Technology (Institute of Science Tokyo).

Abstract:
■Introduction
The combination of WOW (Wafer-on-Wafer) and COW (Chip-on-Wafer) has high potential for 3D manufactruing by using well-established BEOL technology [1]. In the previous study, we developed face-down bumpless COW using Via-last TSVs in order to reduce connection impeadance and total packaging volume as shown in Fig. 1 [2][3][4]. Further stacking using such COW technology is expected to enable high-density chiplet systems and is drawing increasing attention [5]. However, the prediction of warpage induced by each stacking layer has not been studied so far. This paper presents FEM-based evaluation of warpage behavior in a double-stacked 3D structure fabricated using a die-patterned waffle wafer, aiming to establish predictive guidelines for multi-layer COW integration.
Double-Stacked 3D Structure
Figure 2 shows the process flow for fabricating a double-stacked 3D structure using a waffle wafer: a) waffle wafer preparation by dry etching, b) mold resin coating, c) thinning back of the Si and resin layers, d) carrier wafer bonding, e) backside Si thinning of the waffle wafer, f) die bonding onto the backside of the waffle wafer, g) resin molding, and f) carrier wafer debonding. The wafer shape at each process step was monitored, and SEM cross-sectional observation was conducted after final carrier debonding in step h.
Warpage analysis
Figure 3 shows the top of view waffle pattern. The waffle wafer is patterned with trenches measuring 3 mm × 3 mm and 70 µm deep, with die-shaped patterns formed inside each trench on the wafer surface [6]. The silicon thickness from the trench bottom to the wafer backside was 705 µm before thinning and 130 µm after thinning. A large die bonded onto the backside of the waffle wafer has a size of 2.8 mm × 2.8 mm × 200 µm. In the FEM analysis, the temperature was varied from 125 °C to 25 °C, with the resin molding temperature assumed as the stress-free reference state.
■Results and discussion
Figure 4 shows the wafer shape at each step during the stacking process. Since there was no supporting substrate, wafer rigidity was reduced, resulting in significant warpage at step h) due to the remaining thick mold layer. Nevertheless, a double-stacked 3D structure was successfully achieved, as shown in Fig. 5. Except for the secondary molding steps, i.e., f) and h), wafer warpage was measured and compared with simulation results, as shown in Figure 6. Up to step e), which corresponds to Si thinning, the simulation predicted wafer warpage with approximately 5% accuracy, indicating that the FEM analysis is effective for warpage prediction. In the case of secondary molding (step g), the measured wafer warpage differed from the simulation by about 20%, which is attributed to non-uniform mold thickness.
■Conclusion
A double-stacked 3D structure using a waffle wafer is demonstrated for the first time to enable prediction of wafer warpage in multi-COW stacking applications. FEM analysis allowed estimation of wafer warpage with approximately 5% accuracy during the stacking process. These results show that warpage can be predicted in advance, facilitating process design for multi-layer COW stacking.
